Rubix 29" HIGH

Standard Cubicle Storage Freestanding and Mobile cabinets are available in widths of 36", *38", 48", 60" and 72". Available heights include 29", 36", 42", 54" and 72". Cabinets are 18" and 24" deep. Open Tote Rail Storage is only 24"D.

All cabinet tops are high pressure laminate and boxes are available in high pressure laminate, melamine oak veneer and maple veneer finish.

Freestanding units come equipped with 3" support legs and mobile units come equipped with 75mm casters.

Cubicle Storage cabinets come with adjustable shelves.

Not all configurations are available in every dimension combination.

*Note: Tote Rail Storage is incorrectly shown as 18"D in the Anyspace Catalog. Rubix Tote Rail Storage cabinets are 24"D.

See Full Description

Cut Sheets

Rubix 72"W Cut Sheet (.pdf, 972.091 KB)
Rubix 60"W Cut Sheet (.pdf, 855.716 KB)
Rubix 48"W Cut Sheet (.pdf, 836.776 KB)
Rubix 36"W Cut Sheet (.pdf, 893.238 KB)

Forms

Rubix Finish Designator (.pdf, 512.36 KB)

List Price Sheets

Rubix 72"W List Price Sheet (.pdf, 324.373 KB)
Rubix 60"W List Price Sheet (.pdf, 321.367 KB)
Rubix 48"W List Price Sheet (.pdf, 342.864 KB)
Rubix 36"W List Price Sheet (.pdf, 399.617 KB)

Overview

High pressure laminate worksurfaces

Cabinet material options include thermally fused laminate and high pressure laminate with PVC edges and oak or maple veneer with wood edges.

Backs are 3/4” engineered wood
Steel frame is 11-gauge 1-1/4” square steel tubing. Frame assembly is attached to the cabinet using wood screws.
Concealed door hinges and a variety of pulls available.
Full-extension drawers
Tote rails that are stop-and-tilt or fully extractable.
Shelves adjustable in 32mm increments
Rugged 75mm twin wheel locking casters that attach via threaded inserts on the underside of the steel frame assembly.
Freestanding steel support legs are available upon request.
Tote-Rail storage units are in 24" Depth
