Pocket Café Counter

Pocket Café Counter is a quarter-round (90˚) settee with a counter-height work surface integrated into the back panel. It is a great interactive component for team seating applications. Pairs well with round, "D" and "lightbulb" shaped table tops, Pocket Lounge settees and is a great seating option for our Crayon mediasharing table.

Plenty of seating options are available for the counter area. Look at our Toadstool, Push Pop, Bella and Slide Stools for some really great choices.

See Full Description

Cut Sheets
Forms
AutoCAD
List Price Sheets

  • Bench Base and Bench Back Assembly: The bench base assembly is fabricated from 3⁄4” engineered wood with premium grade oak or maple veneer faces or HPL faces. Finished edges of veneer assemblies receive a 3mm solid wood edge. Finished edges of HPL assemblies receive a 3mm PVC edges. Bench Base Assembly is bolted to bench back assembly with metal-to-metal connection. Back panel is fabricated from multiple layers of wiggle board plywood, phenolic backer and laminate sheets. Back panel can be finished in veneer or HPL face and is self-edged.
  • Counter: Counter top is 1” thick engineered wood with .050” high pressure laminate work surface and .030” phenolic backer. Edge is 3mm PVC. Counter is mounted to back through (3) 1” thick veneer ply shelf supports.
  • Leg Assemblies: Legs are fabricated from 5/16 plate steel and include a curved profile with a square mounting plate. The bottom of each leg is fitted with a threaded weld nut and a 1-7/8” black leveling glide.

Connectivity option is available on flat surfaces of the bench base.

Overall Dimensions

Depth: 37-5/32" Width: 96" Overall Height: 46" Seat Height: 18" Counter Height: 36", 42"

Note: Pocket Café Counter is not designed to mate with Duo Lounge or Duo Café Counter. Pocket Café Counter does mate with Pocket Lounge

Upholstery note: fabric patterns that are horizontal may not line up with adjacent furniture due to the backs being curved and tapered.

Fabrics
